BeaconMedaes MEGA3 - Periodic Maintenance:

6-2
MEGA3 NFPA Medical Gas Notification System
4107 9016 59.03
Cleaning:
Use clean dry microfiber cloth or soft lint-
free cloth to remove any smudges located on
the touchscreen. Make sure not to apply too
much pressure on the screen when cleaning
it. Never use paper towels or tissue paper
which contain wood fibers that will scratch
any plastic surface.
Periodic Maintenance:
Inspect the alarm periodically and perform
a self test (see Section 4.1.6 - Information
Screen). This ensures proper operation of the
alarm. Any damaged components inside the
alarm should be replaced by a authorized
BeaconMedæs service technician.
Part Number Gas Sensor Assembly
4107 4016 54 O2 Sensor Assembly
4107 4016 55 N2O Sensor Assembly
4107 4016 56 MedAir Sensor Assembly
4107 4016 57 Vac Sensor Assembly
4107 4016 58 N2 Sensor Assembly
4107 4016 59 IAIR Sensor Assembly
4107 4016 60 WAGD Sensor Assembly
4107 4016 61 CO2 Sensor Assembly
4107 4016 62 CO2-O2 Sensor Assembly
4107 4016 63 O2-CO2 Sensor Assembly
4107 4016 64 HE-O2 Sensor Assembly
4107 4016 65 O2-HE Sensor Assembly
4107 4016 66 HE Sensor Assembly
4107 4016 67 LAB-AIR Sensor Assembly
4107 4016 68 LAB-VAC Sensor Assembly
4107 4016 69 O2-100 Sensor Assembly
4107 4016 70 MedAir-100 Sensor Assembly
4107 4016 71 CO2-100 Sensor Assembly
4107 4016 72 AR Sensor Assembly
4107 4016 73 AGSS Sensor Assembly
4107 4016 74 O2-N2O Sensor Assembly
*Table 1: Gas Sensor Module Options
(Service replacement only)
Part Number I/O Boards Description
4107 4016 37 B05 Power Module Power supply
4107 4016 38 B1X (Signal Input
Board)
20 Inputs
4107 4016 41 B4X (Relay Board) 16 Relay
Outputs
4107 4016 42 B50 (4-20mA Com-
bination Board)
4 Inputs
for 4-20mA
Signals
4107 4016 43 B60 (Gas Input
Board)
8 Gases
4107 4016 44 B65
(Gas Combination
Board)
3 Gases, 7 In-
puts, 6 Relay
Outputs
**Table 2: I/O Boards
