Features & Set-Up
Quick Overview
Before setting up your system, consider the amount of time it would take you to go room-to-room to program
your monitors. In a large environment with many monitors, it may be extremely time-consuming to
program on-site. In this case, we recommend setting up all monitors locally, one-at-a-time, then installing
them in their assigned rooms. This ensures, not only will the monitors be plug-and-play at that point, but you’ll
have an understanding of the basic system functionality, before your scheduled installation date.
To begin, you’ll need to set the IP address of each monitor and door panel either at each component, or
through a network connected computer using the default IP: 192.168.68.90 for each device, one-at-a-time.
*NOTE*: You’ll have conicting IP addresses out of the box if more than one deviced is connected to the
network.
Once addressed, you’ll need a laptop or computer connected at the switch, or within your network to
access the online settings. To access your online settings out of the box, you’ll need to set the PC’s ethernet
controller’s IPv4 address. Assign the PC’s IP to 192.168.68.xxx (x=# of your choice), with a default gateway
of 192.168.68.1. You can then type in the IP address in a browser window of your choice, enter the admin
credentials (default=admin:123456),then adjust settings using the device’s graphical user interface (GUI).
Note: All door stations, except the full-sized A9K model, must be programmed over the network.
Door Station Main Page
(A9K)
Monitor Network Settings
