n
Do not operate the unit under ambient temperatures below -20 °C and abo
-
ve +70 °C.
n
Voltages > 42 V are possible within the transponder.
n
The programming of the address module AM6400-1 with the ICAO 24-bit
address of the aircraft must be carried out by an authorized installation
company or the manfacturer.
4.
Layout of manual
The manual is divided into three chapters:
- GENERAL DESCRIPTION
- INSTALLATION
- OPERATION
5.
Revisions of the manual
All changes to the manual are recorded consecutively on the pre-page “Record of
Revisions”.
6.
List of abbreviations
AA Aicraft Address (24-bit ICAO)
ADLP Avionics Data Link Processor
ADS-B Automatic Dependent Surveillance-Broadcast
AI Aircraft Identifier
ALT Altitude or transponder ALT mode
ATC Air Traffic Control
BIT Built-In Test
CBIT Continuous Built-In Test
CCS Company Call Sign
CS Call Sign
DV Manual identification number
EASA European Aviation Safety Agency
ELS Elementary Surveillance
EHS Enhanced Surveillance
es e = Extended squitter and s = SI capability
FAA Federal Aviation Administration
FL Flight Level
FMS Flight Management System
FN Flight Number
GICB Ground Initiated Comm-B
GND Ground
ICAO International Civil Aviation Organization
IBIT Initiated Built-In Test
ID Identifier
IDT Ident (Identification)
IFR Instrument Flight Rules
INTRO Page 2
34-50-08 September 2011
