Becker PSF+ Series - Technical Data Dia. 45; Technical Data Dia. 58

Technical data dia. 45
Type R8/17C PSF R12/17C
PSF(+)
R20/17C
PSF(+)
R30/17C
PSF(+)
R40/17C
PSF(+)
R50/11C
PSF(+)
Rated torque [Nm] 8 12 20 30 40 50
Output speed [rpm] 17 17 17 17 17 11
Limit switch range 64 revolutions
Supply voltage 230 V AC / 50 Hz
Connected load [W] 100 110 160 205 260 240
Rated current consumption
[A]
0.45 0.50 0.75 0.90 1.15 1.10
Mode S2 4 min
Degree of protection IP 44
Min. tube inside diameter
[mm]
47
Frequency 868.3 MHz
Emission sound pressure
level [dB(A)]
≤ 70
Technical data dia. 58
Type L44/14C PSF(+) L50/17C PSF(+) L60/11C PSF(+) L60/17C PSF(+)*
Rated torque [Nm] 44 50 60 60
Output speed [rpm] 14 17 11 17
Limit switch range 64 revolutions
Supply voltage 230 V AC / 50 Hz
Connected load [W] 255 315 265 380
Rated current consumption
[A]
1.20 1.40 1.20 1.75
Mode S2 4 min
Degree of protection IP 44
Min. tube inside diameter
[mm]
60
Frequency 868.3 MHz
Emission sound pressure
level [dB(A)]
≤ 70
19
