General
These tubular drives are high-quality products with the following features:
• Optimised for sun protection applications
• Suitable for awnings and conservatory shades. Drives of type "+" are specially designed for cassette awnings
• Individual, group and central radio control
• No need to run wires to a switch or relay control device
• Any combination of drive and transmitter possible
• Simple to set the limit positions with the transmitter
• Installation without stops is also possible (from extended point to retracted point without stop)
• Two freely selectable intermediate positions can be set
• Flexible radio grouping; can be altered at any time with no need to install/uninstall
• Automatic detection of limit positions thanks to intelligent electronic system with stop systems
• The final positions do not have to be reset: Changes in the curtains are accommodated automatically when using stop sys-
tems.
• Considerably lower stop load, and thus considerably lower curtain load.
• Smooth operation of the system and the drive increases the service life
• For plug-in connecting cable
Please observe these Assembly and Operating Instructions when installing and setting the equipment.
The date of manufacture comes from the first four digits of the serial number.
The numbers 1 and 2 indicate the year and the numbers 3 and 4 indicate the calendar week.
Example: 24th calendar week in 2012
Ser. No.: 1224XXXXX
Explanation of pictograms
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could
result in injury.
ATTENTION
ATTENTION indicates measures that must be taken to avoid damage to
property.
Denotes user tips and other useful information.
Warranty
Structural modifications and incorrect installation which are not in accordance with these and our other instructions can result in
serious injuries, e.g., crushing of limbs. Therefore, structural modifications may only be carried out with our prior approval and
strictly in accordance with our instructions, particularly the information contained in these Assembly and Operating Instructions.
Any further processing of the products which does not comply with their intended use is not permitted.
The end product manufacturer and fitter have to ensure that all the relevant current statutory, official and, in particular, EMC regu-
lations are adhered to during utilisation of our products, especially with regard to end product manufacture, installation and cus-
tomer advice.
3
