Testing
Pneumatic safety edges are tested for safety-related reasons during every downward
movement. This process is called testing.
Self-test
The control unit carries out a self-test periodically. The relays are controlled audibly.
Maintenance
This control unit is maintenance-free.
Cleaning
Only clean the outside of the housing with a suitable cloth. Do not use cleaning agents,
as these may damage the plastic.
Technical data
Type S30, S30-V..
Mains connection 400 V 3~N PE 50 Hz
Nominal motor rating max. 1.8 kW
Control voltage 12 V DC
Control power max. 200 mA
Housing dimensions (W x H x D) 155 x 130 x 50 mm
Weight approx. 0.5 kg (without connecting cable)
Degree of protection IP54
Ambient temperature range -5°C.....+50°C
On-site fuse protection 3 x 10 A
Limit switching electronic
Interface RS485
