4
Section: General Information
Do NOT Alter the Original
Burner Design
Tampering with or altering the burner design could
seriously impair performance, resulting in loss of
static pressure, damage to the system components,
reduced air volume, heavy smoke, ame
impingement, appliance sooting, hot gas puff-back,
and asphyxiation or re hazards.
Maintain the design to its original conguration.
Only use parts specied for AF or AFG Burners.
Do NOT remove the air guide from the AFG chassis.
Do NOT use ‘M’ Series air tube combinations on AF
Burners.
Never try to convert an AF to an AFG or vice versa
Any design alteration will:
y Void UL Listing
y Void manufacturer’s warranties
y Seriously impact burner performance
y Greatly increase your liability risk
Impaired Burner Performance
and Fire Hazard.
Do NOT operate the burner beyond specications
outlined in the following Table.
y For applications beyond these limits, consult Beckett
Technical Service at 1-800-645-2876.
y NOTE: Some packaged appliances with burners
may be agency listed as a unit to operate beyond
these limits. Consult the appliance manufacturer’s
specications and agency approvals for verication.
If the residence is unattended in severely cold
weather, burner primary control safety lockout,
heating system component failures, power outages
or other electrical system failures could result in
frozen plumbing and water damage in a matter of
hours. For protection, take preventive actions such
as having a security system installed that operates
during power outages, senses low temperature
and initiates an effective action. Consult with your
heating contractor or a home security agency.
Frozen Plumbing and
Water Damage Hazard
Figure 2 – Burner Specications
Capacity
(Note 1)
AF Burner: 0.40 – 3.00 GPH
AFG Burner: 0.40 – 3.00 GPH
Refer to Figure 3, Page 5 for further
information
Certications/
Approvals
ANSI / UL296 and
CSA – B140.0
Approved
Fuels
USA: ASTM D396 for No1 or No.2
Heating Oil & B6 – B20 grades.
Canada: No. 1 Stove Oil or No. 2 Furnace
Oil Only.
SEE WARNING SECTION BELOW
Electrical: Input
Voltage
120 VAC / 60Hz / 1 Phase
Current 5.8 Amps Maximum
Motor Beckett p/n 21805: 1/7 HP, 3450 RPM,
PSC, NEMA 48
Igniter Beckett p/n 51771: Electronic
Solid State rated for continuous duty.
Fuel Pump
(Note 2)
Beckett p/n PF2032x
Solenoid coil 120VAC
Inlet Pressure: 3 psi maximum
Outlet Pressure: 100-200 psi
Air Tube
Combinations
ATC Codes and selection – See Figure 3,
page 5
Dimensions
(Less Tube)
Less Cover:
Height: 10-3/8”
Width: 12-1/2”
Depth: 6-1/2”
With Cover:
Height: 10-3/8”
Width: 12-1/2”
Depth: 9-1/4”
Air Tube: 4.0” Ø
Operating
Temperature
(Note 3)
+32°F (0°C) Minimum
+140°F (60°C) Maximum
Environmental 5% to 95% RH, non-condensing
Use ONLY Fuels Listed for Use
with this Burner
Use of unapproved fuels could result in explosion,
re, personal injury or death, and/or damage to
equipment and property.
y
DO NOT USE Raw Vegetable Oil (RVO) or any fuel
blended with RVO
y DO NOT USE with Flammable Liquids; Gasoline, LP gas,
charcoal lighter uid, etc.
y For a listing of alternative fuels please refer to the Beckett
‘Alternative Fuels and Beckett Burners Technical Bulletin’
Form # 664860.
Note 1: Approval Agency listings rate these burners for 0.40 – 3.00
GPH. However, the ring rate range is limited by the specic air tube
combination being used. Refer to Figure 3, Page 5.
Note 2: See appliance manufacturer’s burner specications for recom-
mended pump discharge pressure.
Note 3: Operating temperatures above or below listed specications
must be approved by RW Beckett Engineering
To Next Page
