AFG Burner Manual
Section: General Information
Please read and understand the manual supplied with
this equipment. This equipment must be installed,
adjusted and put into operation only by a qualied
individual or service agency that is:
y Licensed or certied to install and provide technical
service to oil heating systems.
y Experienced with all applicable codes, standards
and ordinances.
y Responsible for the correct installation and
commission of this equipment.
y Skilled in the adjustment of oil burners using
combustion test instruments.
The installation must strictly comply with all applicable
codes, authorities having jurisdiction and the latest
revision of the National Fire Protection Association
Standard for the installation of Oil-burning Equipment,
NFPA 31 (or CSA-B139 and CSA-B140 in Canada).
Regulation by these authorities take precedence over
the general instructions provided in this installation
manual.
Incorrect installation, adjustment, and
use of this burner could result in severe
personal injury, death, or substantial
property damage from re, carbon
monoxide poisoning, soot or explosion.
Professional Service
Required
Special Requirements
○ Burner and/or appliance installations in the United
States must comply with NFPA 31 (National Fire
Protection Association) Standard for the Installation
of Oil-Burning Equipment, NFPA 70 (National
Electric Code), as well as all state and local codes
(AHJ)
○ Installations in Canada must comply with the latest
editions of CSA B139 (Installation Code for Oil
Burning Equipment), CSA Standard C22, Part 1
(Canadian Electric Code), and all applicable local
codes.
○ Concealed damage — If you discover damage to
the burner or controls during unpacking, notify the
carrier at once and le the appropriate claim.
○ When contacting Beckett for service information —
Please record the burner serial number (and have
available when calling or writing). You will nd the
serial number on the silver label located on the left
rear of the burner. Refer to Figure 1, Page 3
Note: ATC's for specic manufacturers are listed in the Beckett OEM Specication Guide and can also be found by
visiting www.beckettcorp.com.
Fuel Supply System
Compatibility
The fuel supply system design and components must
be compatible with the fuel being used in the appliance.
Follow all guidelines and best practices recommended
by the fuel supplier, NFPA 30 & NFPA 31, and any
state or local ordinances for safe storage, ltering,
conditioning, and delivery to the burner.
Figure 3: Model AF / AFG Air Tube Combination (ATC) Codes
Firing Rate
GPH (min-max)
Head Static Plate
Size (inches)
ATC Codes For Usable Air Tube Lengths
4-1/2” 5-3/8” 6-5/8” 7-1/4” 9” 10-1/2” 13” 16”
- None 2-3/4 U AF44 AF53 AF65 AF72 AF90 AF104 AF130 AF160
0.50 - 0.75 F0 3-3/8 U AF44XR AF53XR AF65XR AF72XR AF90XR AF104XR AF130XR AF160XR
0.75 - 1.25 F3 2-3/4 U AF44XN AF53XN AF65XN AF72XN AF90XN AF104XN AF130XN AF160XN
0.85 - 1.35 F4 2-3/4 U AF44WH AF53WH AF65WH AF72WH AF90WH AF104WH AF130WH AF160WH
0.85 - 1.65 F6 2-3/4 U AF44YB AF53YB AF65YB AF72YB AF90YB AF104YB AF130YB AF160YB
1.10 - 2.00 F12 2-3/4 U AF44XO AF53XO AF65XO AF72XO AF90XO AF104XO AF130XO AF160XO
1.65 - 2.50 F22 2-3/4 U AF44XP AF53XP AF65XP AF72XP AF90XP AF104XP AF130XP AF160XP
2.50 - 3.00 F31 None AF44XS AF53XS AF65XS AF72XS AF90XS AF104XS AF130XS AF160XS
Model AFG Type “M” Air Tube Combination (ATC) Codes
Firing Rate GPH
(min-max)
Head Static Plate
Size (inches)
Venturi ATC Codes For Usable Air Tube Lengths
5” 7” 9”
0.50 - 1.10 L1 3-3/8 U 8 holes AFG50MBSS AFG70MBSS AFG90MBSS
0.50 - 1.00 L2 2-3/4 U 8 holes AFG50MPSS AFG70MPSS AFG90MPSS
0.75 - 2.75 V1 2-3/4 U 8 holes AFG50MDSS AFG70MDSS AFG90MDSS
