Beckett SF Series User Manual

2
To the Owner:
Thank you for purchasing a Beckett
burner for use with your heating appliance.
Please pay attention to the Safety Warnings
contained within this instruction manual.
Keep this manual for your records and
provide it to your qualied service agency
for use in professionally setting up and
maintaining your oil burner.
Your Beckett burner will provide years of
efcient operation if it is professionally
installed and maintained by a qualied
service technician. If at any time the burner
does not appear to be operating properly,
immediately contact your qualied
service agency for consultation.
We recommend annual inspection/
service of your oil heating system by a
qualied service agency.
Daily – Check the room in which your
burner/appliance is installed. Make sure:
• Air ventilation openings are clean and
unobstructed
• Nothing is blocking burner inlet air
openings
• No combustible materials are stored
near the heating appliance
• There are no signs of oil or water
leaking around the burner or appliance
Weekly
• Check your oil tank level. Always
keep your oil tank full, especially
during the summer, in order to prevent
condensation of moisture on the inside
surface of the tank.
Remainder of manual to be used ONLY BY
QUALIFIED SERVICE TECHNICIANS
▼
▼
Contents
General Information ....................................................3
Hazard Denitions: ........................................................................ 3
Inspect/Prepare Installation Site ................................5
Inspect Chimney or Direct Vent System ........................................ 6
Combustion Air Supply .................................................................. 6
Clearances to Burner and Appliance ............................................. 7
Combustion Chamber — Burner Retrotting ................................ 7
Prepare the Burner ......................................................7
Burner Fuel Unit ............................................................................ 7
Attach Air Tube (if not already installed) ....................................... 7
Install Burner Nozzle (if not already installed) .............................. 7
Check/Adjust Electrodes ............................................................... 8
Servicing Nozzle Line Assembly ................................................... 8
Mount Burner on Appliance .......................................8
Mounting Options .......................................................................... 8
Mounting Dimensions .................................................................... 8
Installing the Oil Tank and Supply System .................................. 10
Connect Fuel Lines ..................................................................... 10
Wire Burner ................................................................ 11
Burner Packaged with Appliance .................................................11
Burner Installed at Jobsite ............................................................11
Burner Controls .........................................................12
GeniSys 7505 & 7575 ................................................................. 12
Features ...................................................................................... 12
Wiring .......................................................................................... 12
Reset Button Operation ............................................................... 15
Wire Burner ................................................................................. 16
Start Up Burner/Set Combustion .............................16
Cad Cell Resistance Measurement ............................................. 16
Resetting From Restricted or Hard Lockout ................................ 16
Startup / Checkout ...................................................................... 17
Check Safety Features ................................................................ 17
Set combustion with instruments ................................................ 17
Perform Regular Maintenance..................................18
Shutting the Burner Off ............................................................... 18
Replacing the blower wheel: ....................................................... 18
Replacement Parts ....................................................19
Limited Warranty Information ..................................20
