Beckhoff BC8050 User Manual

Product overview
BC8050 und BC815012 Version: 3.0.0
Technical data BC8050/BC8150
Digital peripheral signals 2040 inputs/outputs
Analog peripheral signals 1024 inputs/outputs
Configuration possibility via TwinCAT or the controller
Maximum fieldbus byte
number
depending on fieldbus
Maximum number of bytes -
PLC
2048bytes of input data, 2048bytes of output data
Bus connection D-sub,9-pin
Power supply (Us) 24V
DC
(-15% /+20%) Use a 4A fuse or an NEC Class2 power supply to
meet the UL requirements!
Input current (Us) 60mA + (total K-bus current)/4
Starting current approx. 2.5 x continuous current
K-bus current (5V) maximum 1000mA
Power contact voltage (Up) maximum 24V
DC
Power contact current load
(Up)
maximum 10A
Recomm. back-up fuse (Up) ≤10A
Dielectric strength 500V (power contact/supply voltage/fieldbus)
Weight approx. 100g
Dimensions (W x H x D) approx. 44mm x 100mm x 68mm
Permissible ambient
temperature range during
operation
-25°C ... +60°C
Permissible ambient
temperature range during
storage
-40°C ... +85°C
Relative humidity 95% no condensation
Vibration/ shock resistance conforms to EN60068-2-6/ EN60068-2-27
EMC immunity/ emission conforms to EN61000-6-2/ EN61000-6-4
Installation position variable
Protection class IP20
