Product overview, digital output terminals
EL20xx, EL212448 Version: 5.2
2.4.1 EL2032, EL2034 - Technical data
Technical data EL2032 EL2034
Number of outputs 2 4
Reverse voltage protection yes
Load type ohmic, inductive, lamp load
Rated voltage of the outputs 24V
DC
(-15%/ +20%)
Switching times T
ON
: 40µs typ.; T
OFF
: 200µs typ.
Output current max. per channel max. 2A (short-circuit-proof)
Short circuit and open circuit detection
yes;open circuit detection [}47] from approx. 1A regular output current
Switch-off energy (inductive) < 1,7J/channel
Current consumption from load voltage typ. 12mA + load typ. 14mA + load
Supply voltage for electronic via E-Bus
Current consumption via E-bus typ. 100mA typ. 120mA
Electrical isolation 500V (E-bus/field voltage)
Bit width in the process image 2 output bits, 2 input bits (diagnostic) 4 output bits, 4 input bits (diagnostic)
Configuration no address setting, configuration via TwinCAT System Manager
Weight approx. 55g
Permissible ambient temperature range dur-
ing operation
-25°C ... +60°C (extended temperature range)
Permissible ambient temperature range dur-
ing storage
-40°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15 mm x 100 mm x 70 mm (width aligned: 12 mm)
Mounting [}72]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance according to EN 60068-2-6/EN 60068-2-27,
see also Installation instructions for terminals with increased mechanical load capacity
[}74]
EMC resistance burst/ESD conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Approval CE
cULus [}150]
ATEX [}82]
