2.6.1 EL2084, EL2088 - Technical data
Technical data EL2084 EL2088
Number of outputs 4 8
Load type ohmic, inductive, lamp load
Nominal voltage of the outputs 24V
DC
(-15%/ +20%)
Output current max. per channel max. 0.5A (short-circuit-proof) max. 0.5A (total current 3A)
Current consumption from load voltage typ. 30mA + load
Supply voltage for electronic via the E-Bus
Current consumption via E-bus typ. 100mA typ. 110mA
Electrical isolation 500V (E-bus/field voltage)
Bit width in the process image 4 output bits 8 output bits
Configuration no address setting, configuration via TwinCAT System Manager
Weight approx. 70g
Permissible ambient temperature range dur-
ing operation
0°C ... + 55°C 0°C ... + 55°C
(aligned in horizontal installation position)
0°C ... + 45°C
(all other installation positions,
see Note [}78])
Permissible ambient temperature range dur-
ing storage
-25°C ... + 85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15mm x 100mm x 70mm (width aligned: 12mm)
Mounting [}72]
on 35mm mounting rail conforms to EN 60715
Vibration/shock resistance according to EN 60068-2-6/EN 60068-2-27,
see also Installation instructions for terminals with increased mechanical load capacity
[}74]
EMC resistance burst/ESD conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
see note [}78]
Approval CE
cULus [}150]
ATEX [}81]
