2.7.1 EL2124 - Technical data
Technical data EL2124
Number of outputs 4
Load type ohmic, inductive, lamp load
Nominal output voltage 5V
DC
(CMOS output)
Switching times T
ON
: < 1µs typ.; T
OFF
: < 1µs typ.
Output current max. per channel ±20mA (short-circuit-proof) per channel, 8mA signal current, type
CMOS output
Supply voltage for electronic via the E-Bus
Current consumption via E-bus typ. 130mA
Current consumption from load voltage (power contacts) typ. 12mA + load
Electrical isolation 500V (E-bus/field voltage)
Bit width in the process image 4 output bits
Configuration no address setting, configuration via TwinCAT System Manager
Weight approx. 70g
Permissible ambient temperature range during operation 0°C ... + 55°C
Permissible ambient temperature range during storage -25°C ... + 85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15mm x 100mm x 70mm (width aligned: 12mm)
Mounting [}72]
on 35mm mounting rail conforms to EN 60715
Vibration/shock resistance according to EN 60068-2-6/EN 60068-2-27,
see also Installation instructions for terminals with increased me-
chanical load capacity [}74]
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP 20
Installation position variable
Approval CE
cULus [}150]
ATEX [}81]
