Beckhoff EL500 Series User Manual

Product overview
EL500x14 Version: 3.6
2.1.2 Technical data
Technical data EL5001 EL5002
Encoder connection binary input: D+, D-; binary output: Cl+, Cl-
Supply of power to the internal SSI
electronics
24V
DC
via the power contacts
Current consumption from the power
contacts (without encoder)
Typically 20mA (without sensor load current)
Encoder supply 24V
DC
via power contacts if necessary via EL91xx potential
distributor terminal
Data transfer rate adjustable up to 1MHz (500kHz preset)
Serial input 24bit width (adjustable)
Data direction Read
Distributed Clocks yes (from FW11) yes
Signal output Differential signal (RS422)
Signal input Differential signal (RS422)
Supply voltage for electronics via the E-bus
Current consumption via E-bus typ. 120mA typ. 130mA
Electrical isolation 500V (E-bus/field voltage)
Bit width in process image default: Inputs 1 x 32-bit data, 1 x 8-bit status
Configuration via TwinCAT System Manager
Weight approx. 55g
Permissible ambient temperature range
during operation
-25°C ... +60°C
(extended temperature range)
Permissible ambient temperature range
during storage
-40 °C ... +85 °C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15mm x 100mm x 70mm (width aligned: 12mm)
Mounting [}31]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6/EN 60068-2-27,
see also Installation instructions [}34] for terminals with
enhanced mechanical load capacity
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Approval CE
ATEX [}42]
cULus [}43]
