Beckhoff EL500 Series User Manual

Commissioning
EL500x142 Version: 3.6
Index F000 Modular device profile
Index (hex) Name Meaning Data type Flags Default
F000:0 Modular device profile General information for the modular device profile UINT8 RO 0x02 (2
dec
)
F000:01 Module index dis-
tance
Index distance of the objects of the individual chan-
nels
UINT16 RO 0x0010 (16
dec
)
F000:02 Maximum number of
modules
Number of channels UINT16 RO 0x0001 (1
dec
)
Index F008 Code word
Index (hex) Name Meaning Data type Flags Default
F008:0 Code word reserved UINT32 RW 0x00000000 (0
dec
)
Index F010 Module list
Index (hex) Name Meaning Data type Flags Default
F010:0 Module list Length of this object UINT8 RW 0x01 (1
dec
)
F010:01 SubIndex 001 - UINT32 RW 0x000001F5
(501
dec
)
5.6 EL5001-0090
The EL5001-0090 supports the full functionality of the EL5151 (please refer to chapter “EL5001 - Operating
modes and settings [}114]”).
In addition, the EL5001-0090 supports the TwinSAFE SC
5.6.1 TwinSAFE SC
5.6.1.1 TwinSAFE SC - operating principle
The TwinSAFE SC (Single Channel) technology enables the use of standard signals for safety tasks in any
networks of fieldbuses. To do this, EtherCAT Terminals from the areas of analog input, angle/displacement
measurement or communication (4…20 mA, incremental encoder, IO-Link, etc.) are extended by the
TwinSAFE SC function. The typical signal characteristics and standard functionalities of the I/O components
are retained. TwinSAFE SC I/Os have a yellow strip at the front of the housing to distinguish them from
standard I/Os.
The TwinSAFE SC technology enables communication via a TwinSAFE protocol. These connections can be
distinguished from the usual safe communication via Safety over EtherCAT.
The data of the TwinSAFE SC components are transferred via a TwinSAFE protocol to the TwinSAFE logic,
where they can be used in the context of safety-relevant applications. Detailed examples for the correct
application of the TwinSAFE SC components and the respective normative classification, which were
confirmed/calculated by TÜV SÜD, can be found in the TwinSAFE application manual.
5.6.1.2 TwinSAFE SC configuration
The TwinSAFE SC technology enables communication with standard EtherCAT terminals via the Safety over
EtherCAT protocol. These connections use another checksum, in order to be able to distinguish between
TwinSAFESC and TwinSAFE. Eight fixed CRCs can be selected, or a free CRC can be entered by the user.
By default the TwinSAFE SC communication channel of the respective TwinSAFE SC component is not
enabled. In order to be able to use the data transfer, the corresponding TwinSAFE SC module must first be
added under the Slots tab. Only then is it possible to link to a corresponding alias device.
