2.2.2 Technical data
Technical data EL5001-0011
Encoder connection Data input: D+, D-; clock input: Cl+, Cl-; RS422
differential signal
Supply of power to the internal SSI electronics 24V
DC
via the power contacts
Encoder supply 24V
DC
via the power contacts
Input frequency/clock rate 125KHz - 1MHz, automatically set
Data width 1 - 32 bits
Coding Gray, dual
Power Fail Bit activatable
Distributed Clocks yes
Supply voltage for electronics via the E-bus
Current consumption via E-bus typ. 130mA
Electrical isolation 500V (E-bus/field voltage)
Configuration via TwinCAT System Manager
Weight approx. 100 g
Permissible ambient temperature range during
operation
-25°C ... +60°C
(extended temperature range)
Permissible ambient temperature range during
storage
-40°C ... +85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 27mm x 100mm x 70mm (width aligned:
24mm)
Mounting [}31]
on 35 mm mounting rail conforms to EN 60715
Vibration/shock resistance conforms to EN 60068-2-6 / EN 60068-2-27
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Approval CE
ATEX [}42]
cULus [}43]
