2.2 EL6631-0010 - Technical data
Technical data EL6631-0010
Bus system PROFINET RT Device
Number of Ethernet ports 2
Ethernet interface 10BASE-T/100BASE-TX Ethernet with 2 x RJ45
Cable length up to 100 m twisted pair
Data transfer rate 10/100 Mbit/s, IEEE 802.3u Auto negotiation, half or full duplex at 10 and
100 Mbit/s possible, automatic settings
Diagnostics Status LEDs
Power supply via the E-bus
Current consumption via E-bus typ. 400 mA
Electrical isolation 500 V (E-Bus/Ethernet)
Bit width in process image variable (max. 2KB for inputs and outputs)
Configuration via the TwinCAT System Manager
Weight approx. 75 g
Permissible ambient temperature range during operation 0°C ... + 55°C (aligned in horizontal installation position)
0°C ... + 45°C (all other installation positions, see Note [}21])
Permissible ambient temperature range during storage -25°C ... + 85°C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 26 mm x 100 mm x 52 mm (width aligned: 23 mm)
Mounting [}23]
on 35 mm mounting rail conforms to EN 60715
Vibration/ shock resistance conforms to EN60068-2-6/ EN60068-2-27
EMC immunity/ emission conforms to EN61000-6-2/ EN61000-6-4
Protection class IP20
Installation position
see notice [}21]
Approvals/ markings*
CE, cULus [}29], UKCA, EAC, ATEX [}27], IECEx [}28]
*) For real applicable approvals/markings see type plate on the side (product labeling).
Ex markings
Standard Marking
ATEX II 3 G Ex nA IIC T4 Gc
IECEx Ex nA IIC T4 Gc
