Technical data
30 ─── Version: 1.0XPlanar
4.3
Data for operation and en-
vironment
Beckhoff products are designed for operation under certain environ-
mental conditions, which vary according to the product. The follow-
ing specifications must be observed for operation and environment
in order to achieve the optimum service life of the products.
Operate the XPlanar only under the specified conditions
Operate the Beckhoff XPlanar only under the operating and ambi-
ent conditions specified in this chapter. This ensures a long service
life and proper operation.
The service life of the system may be shortened at temperatures
above 40°C. Speak to our Applications Department in case of de-
viating environmental conditions and operating states of your ma-
chine or plant.
Environmental requirements
Climate category - operation 2K3 according to EN 60721
Ambient temperature during operation +5 to +40°C
Ambient temperature during transport -25 to +65°C
Ambient temperature during storage -25 to +65°C
Power derating For site altitudes higher than 1000 to 2000m above sea level and
40°C:
1.5% per 100m
Installation altitude ≤2000m*
Permissible humidity in operation 15% to 95% relative humidity, no condensation
Degree of pollution 2 according to IEC60664-1
*For applications at greater installation altitudes, please contact your local Beckhoff office or support@beck-
hoff.com
Specifications for intended use
Ventilation via convection
Insulation material class F according to IEC 60085; UL1446 class F
Protection class IP40
Installation position Horizontal, stator surface upwards
Vibration resistance, horizontal, stator
facing upwards
conforms to EN 60068-2-6
Shock resistance conforms to EN 60068-2-27
EMC requirements conforms to EN61000-6-2 / EN61000-6-4
Approvals CE
In preparation: cURus, EAC
Overvoltage category III according to IEC60664-1
