Beckhoff XPlanar User Manual

Technical data
Version: 1.0 ─── 31XPlanar
4.4
Tiles
Tiles APS4322
Execution Standard
Maximum angle of rotation C axis [°] ± 5
Maximum position resolution [µm; °] 1 X, Y, Z; 0.001 A, B, C
Dimensions [mm] 240 x 240 x 66
4.5
Mover
Mover APM4220 APM4330 APM4550
Velocity [m/s] 2
Acceleration without payload [m/s
2
] 10
Maximum payload at 1mm flight
height[kg]
0.4 1.5 4.0
Surface Aluminum housing (blasted), underside plastic film
Dimensions [mm] 113 x 113 x 12 155 x 155 x 12 235 x 235 x 12
