Beckhoff XPlanar User Manual

Technical data
32 ─── Version: 1.0XPlanar
4.6
XPlanar
Electrical data XPlanar
Auxiliary supply (control voltage)
Input voltage [V
DC
] 24 ±20%
Input current in standby[A] 0.25
Input current with mover[A] 0.5
Input current with mover and fan[A] 0.85
Max. current consumption 24V[ADC]
without fan 0.5
with fan 0.85
Power supply
Input voltage [V
AC
] 100to240±10%
Input frequency [Hz
AC
] 50to60±10%
Input current[A
AC
] 1.0to 2.3
Inrush current peak at 230V[A] 7.3
Inrush current peak at 115V[A] 3.65
Power consumption per tile
in standby, without mover, at 24V[W] 6
in standby, without mover, at mains volt-
age[W]
2
Maximum, continuous [W] 240
Maximum, short-term [W] <400
Tiles per power supply 1to10
Average power consumption per mover
at 1mm flight height
APM
4220 4330 4550
without load, standstill[W] * 35 *
with 1.5kg load, standstill[W] * 120 *
*For further information contact your local Beckhoff office or support@beckhoff.com.
Mechanical data
Tiles APS
4322
Length [mm] 240
Width [mm] 240
Height [mm] 66
Weight [g] 5725
Mover APM
4220 4330 4550
Length [mm] 113 155 235
Width [mm] 113 155 235
Height [mm] 12 12 12
Weight [g] 628 1237 3414
Protection class
Standard housing version IP40
