Beckhoff XPlanar

Technical data
Version: 1.0 ─── 35XPlanar
4.7.2Mover
• All figures in millimeters
APM4220-0000
M4 x 6 (4x)
86 □
113 □
12,1
8
6
Ø4 H7 x 4,5 (2x)
98 □
APM4330-0000
M4 x 6 (4x)
128 □
155 □
M4 x 6 (4x)
32 □
Ø4 H7 x 8 (2x)
M6
3
2
12,1
140 □
