What to do if rotor calibration error in Beckman Coulter Avanti J-E Laboratory Equipment?
Make sure the rotor in use is a compatible Beckman Coulter rotor (see AVAILABLE ROTORS in Section 1). For further assistance, contact Beckman Coulter service.
What to do if there is no rotor installed in Beckman Coulter Laboratory Equipment?
If your Beckman Coulter Laboratory Equipment indicates that there is no rotor installed, or that the drive belt is loose or broken, first install the rotor according to the applicable rotor manual. If the rotor is installed when the message appears, contact Beckman Coulter Customer Service.
What to do if required vacuum level not reached in Beckman Coulter Avanti J-E Laboratory Equipment?
If your Beckman Coulter Laboratory Equipment is not reaching the required vacuum level in the allowed time, check and clean the door sealing area and door gasket. Also, wipe any ice and excess moisture from the chamber. If the issue continues, contact Beckman Coulter Customer Service.
What is the reason for leakage of uncapped tubes in Beckman Coulter equipment?
If uncapped tubes are leaking in your Beckman Coulter equipment, it's likely because the tube volume exceeds the maximum uncapped volume.
What to do if the system cannot identify the rotor in Beckman Coulter Laboratory Equipment?
Make sure the rotor in use is a compatible Beckman Coulter rotor (see AVAILABLE ROTORS in Section 1). For further assistance, contact Beckman Coulter service.
What to do if there is a problem with the system control software, EPROM, or RAM in Beckman Coulter Avanti J-E Laboratory Equipment?
Call Beckman Coulter service.
What to do if the entered rotor number is not the same as the rotor identified in Beckman Coulter Laboratory Equipment?
Press [CE] to clear the message and enter the correct rotor entry code.
What to do if required vacuum level is not reached in allowed time in Beckman Coulter Laboratory Equipment?
Check and clean the door sealing area and door gasket. Wipe any ice and excess moisture from the chamber. For further assistance, contact Beckman Coulter service.
Why are my Beckman Coulter tubes collapsing?
Tube collapse in Beckman Coulter equipment can occur due to several reasons: * Insufficient thinwall tube volume: The meniscus should be 2 to 3 mm below the tube top to provide adequate tube wall support. * Moisture: Ensure that tubes and tube cavities or buckets are dry before inserting the tubes, as moisture can cause the tube to float and collapse. * Reagent incompatibility: Refer to Chemical Resistances for chemical compatibilities of the tube material and chemicals used. * Excessive speed: Refer to the applicable rotor manual for maximum speeds to ensure tubes are not run above their rated speed.
Why is my Beckman Coulter bottle leaking (bottles with cap assemblies)?
Leakage in bottles with cap assemblies in Beckman Coulter equipment can occur due to: * Moisture or lubrication on the cap or sealing surface. Ensure the O-ring, plug, and bottle lip are dry and free of lubrication before use. * A damaged or defective O-ring or gasket. Replace the O-ring or gasket. * Insufficiently tightened cap. Tighten the cap securely. * An uneven sealing surface on the bottle. Replace the bottle. * Overfilled tube. If using threaded caps without inserts or O-rings, keep the meniscus lower to prevent leakage.
Added JA-14.50 rotor and related tables.
Changed Polyallomer to polypropylene in several chapters.
Added Avanti JXN-30, JXN-26 Centrifuges, and JA-18 Rotor.
Explains the meaning of safety alert symbols and terms.
Discusses handling of chemical and biological hazards.
Covers safety precautions related to mechanical aspects of rotors and centrifuges.
Explains RoHS compliance labels and their meaning.
Details what the manual covers and how it should be used.
Provides an overview of rotor types, selection, and operation.
Describes the basic characteristics and types of rotors.
Guides users on how to select the appropriate rotor for their application.
Discusses the materials used in the construction of rotors.
Explains the function and importance of drive pins in rotor installation.
Describes fixed-angle, swinging-bucket, vertical-tube, and rack-type rotors and their uses.
Explains how pelleting separates particles based on sedimentation coefficients.
Methods of particle separation based on density and sedimentation coefficient.
Centrifugation as a method for processing blood components.
General guidelines for operating centrifuges and rotors.
Explains how to balance rotor loads for stable operation.
Describes devices and procedures for securing rotors to the drive spindle.
Explains mechanisms to prevent rotors from exceeding their rated speeds.
Discusses conditions that may require reducing maximum allowable rotor speeds.
Explains the need for temperature compensation and how to set it.
Provides instructions for setting temperature compensation on different centrifuge models.
Introduces labware used in Beckman Coulter J series rotors.
Discusses factors influencing the choice of labware for centrifugation.
Details chemical compatibility of labware materials with solvents and samples.
Describes various types of tubes, bottles, and accessories.
Covers methods for capping and sealing tubes, bottles, and plates.
Guidelines for recovering samples from rotors, buckets, and carriers.
Contains general instructions for filling, capping, and sample recovery.
Discusses methods for preparing density gradients using gradient formers.
Provides general requirements for filling and sealing tubes and bottles.
Discusses safety precautions when handling physiological fluids.
Instructions for filling open-top tubes for various rotor types.
Details on capping tubes, including types of caps and requirements.
Instructions for filling and capping polycarbonate and polypropylene bottles.
Instructions for filling and loading labware cups in the JS-5.0 Rotor.
Step-by-step guide for filling and heat-sealing Quick-Seal tubes.
Procedures for sealing Quick-Seal tubes using different methods.
Instructions for capping multiwell titer plates using cap strips or foil lids.
General instructions for filling and capping tubes and bottles with adapters.
Details the use of Aerosolve canisters to minimize aerosol leakage.
Instructions for loading blood bags into cups for centrifugation.
Provides a method to make Ultra-Clear tubes wettable.
Introduces the use of fixed-angle rotors in J series centrifuges.
Describes the features and applications of fixed-angle rotors.
Step-by-step instructions for preparing and loading fixed-angle rotors.
Details operating procedures for fixed-angle rotors.
Procedures for removing rotors and recovering samples.
Introduces the use of swinging-bucket rotors in J series centrifuges.
Describes the features and applications of swinging-bucket rotors.
Step-by-step instructions for preparing and loading swinging-bucket rotors.
Explains the importance and methods of symmetric and balanced loading of buckets/carriers.
Details operating procedures for swinging-bucket rotors.
Guidelines for recovering samples from swinging-bucket rotors.
Introduces the use of vertical-tube and rack-type rotors.
Describes the features and applications of vertical-tube and rack-type rotors.
Explains the function and use of vertical-tube rotors.
Describes the function and use of rack-type rotors.
Instructions for preparing and loading rack-type rotors.
Procedures for removing rack-type rotors and recovering samples.
Provides information on rotor and accessory care, and troubleshooting.
Covers regular cleaning, inspection, corrosion prevention, and lubrication of rotors.
Details cleaning procedures for rotors and their components.
Discusses methods for sterilizing and disinfecting rotors and components.
Emphasizes the importance of regular inspection for rotor condition.
Explains lubrication procedures for rotor components like O-rings and pivot pins.
Lists common operating problems and their suggested solutions.
Refers to a separate document for chemical resistance data.
Introduces tables of temperature compensation units for various rotors.
Explains the need for temperature compensation and how to set it.
Provides reference information on commonly used gradient materials.
Provides an overview of blood separation procedures using Beckman Coulter J series centrifuges.
Describes the composition of blood and the process of component separation.
Details common blood components and their typical applications.
Explains centrifugation techniques for blood component separation.
Offers tips for safe and efficient blood component centrifugation runs.
Lists documents and publications related to the manual's content.
General| Model | Avanti J-E |
|---|---|
| Manufacturer | Beckman Coulter |
| Maximum Speed | 21, 000 rpm |
| Temperature Range | -10°C to 40°C |
| Control Interface | Digital |
| Weight | 400 kg |
| Refrigeration System | CFC-free |
| Power Requirements | 200-240 V, 50/60 Hz |
