The Logica FM Control Unit by Beghelli (code 21102) is a device designed for the centralised con-
trol of normal and emergency lighting systems: it controls and supervises up to 992 Logica FM
series luminaires via radio. The Logica FM Control Unit by Beghelli consists of:
- Keyboard + display for user operations;
- Radio interface on the 2.4GHZ-2.4835GHz band, (code 12130) DSSS “Spread Spectrum” modu-
lation for connection to Logica FM series luminaires;
- RS485 interface for direct connection to a PC.
- RS232 interface for connection to the Logica DIN RS232 serial printer by Beghelli (code
3284).
- USB interface for software updates, back-up and restoring configuration data.
- Integrated 4G LTE modem for remote connections via Internet.
- Ethernet interface for LAN networks.
- Wi-Fi interface for PC connection.
To control the system from a remote PC, you need to get the Logica Visual software (code
12139) or the SD Manager software (code 20109).
The Logica FM Control Unit performs the following tasks:
SYSTEM MONITORING
The Logica FM Control Unit continuously monitors the luminaires connected to it and it detects
and signals any malfunctions.
SYSTEM CONTROL
The Logica FM Control Unit allows you to adjust the brightness of luminaires, to perform
Functional and Autonomy Tests on emergency luminaires in the system, to schedule tests
(date, time and time intervals) etc.
KEEPING A LOGBOOK
The Logica FM Control Unit tracks test outcomes and, in general, any relevant operation in the
system. If a printer is available (code 3284), this information can be regularly printed on paper.
If a PC connection is available, this information can be sent and saved on a computer.
