76
Technical Data
Capacitance
Range Tolerance
50.00 nF ±(0.8% + 3d)
500.0 nF ±(0.8% + 3d)
5.000 µF ±(1.0% + 3d)
50.00 µF ±(2.0% + 3d)
500.0 µF ±(3.5% + 5d)
9999 µF ±(5.0% + 5d)
Acoustical Continuity Test
Beep at approx. 20...200V. (response-time < 100µs)
Frequenzy
Tolerance: ±(0.01% + 2d)
Measuring function Input Sensitivity Range
mV 300 mV 5 Hz ... 125 kHz
5 V 2 V 5 Hz ... 125 kHz
50 V 20 V 5 Hz ... 20 kHz
500 V 80 V 5 Hz ... 1 kHz
1000 V 300 V 5 Hz ... 1 kHz
V, Cx, diode 300 mV 5 Hz ... 125 kHz
mA, mA, A 10% of 5 Hz ... 125 kHz
measurement range
