Parts List30 iNUKE NU6000DSP
Quantity Item Rev Description Reference Designators Notes
20 1.0000 A76-00000-13575 CABLE;AC-CORD;3;AR;1500 MM;Plug +
Connector:321+730;H05VV-F 3G1.0
(AR)
21 2.0000 A77-00000-03134 CABLE;STRANDWIRE;AWG:16;UL1672;COMMON;120
MM;BLUE;S/T 5mm;6.3mm AMP
[P0AEO:03: {2.0}()]
22 1.0000 A76-15060-05755 CABLE;AC-
CORD;W/POLYBAG;LENGTH:150cm;POLES:3;227 IEC 53
(RVV) 3x1mm2;VERSION:CCC
(CCC)
23 1.0000 A76-18050-05757 CABLE;AC-CORD;LENGTH:180cm;PLUG:HE105
ISOLATED;SAA H05VV-F 3x1mm2;CONN.HP-
3;VERSION:SAA
(SAA)
24 1.0000 A77-00000-24203 CABLE;STRANDWIRE;AWG:16;UL1015;3;160
MM;BLACK/BLUE/RED;S/T:5mm; 6.mm AMP-
CONNECTOR ISOLATED;TWIST
[P0AEO:03: {1.0}()]
25 1.0000 A74-00000-26890 CABLE;FLAT;AWG:28;UL2651;2.54 MM;14;150 MM;PIN1
RED;FC-14P;FD-14P
[P0AEO:03: {1.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
26 1.0000 A74-00000-26890 CABLE;FLAT;AWG:28;UL2651;2.54 MM;14;150 MM;PIN1
RED;FC-14P;FD-14P
[P0AEO:03: {1.0}()]
Circuit Protector
Quantity Item Rev Description Reference Designators Notes
1 1.0000 B20-00000-39637 CIRCUIT BREAKER;12 A;V;RONGFENG;RFLB;TRIP TIME
10s+/-5s2 TIMES OVERLOAD
(EU, UK, SAA, CCC,
AR, BR1)
2 1.0000 B20-00000-39640 CIRCUIT BREAKER;25 A;V;RONGFENG;RFLB;TRIP TIME
10s+/-5s2 TIMES OVERLOAD
(UL, JP)

Behringer iNuke NU6000DSP Specifications

General

Amplifier class	D
Audio output channels	- channels
Peak power per channel	6000 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %
RMS power output per channel (4 Ohm)	3100 W
RMS power output per channel (8 Ohm)	1600 W
USB 2.0 ports quantity	1
Speakers connectivity type	XLR / 1/4\
Purpose	Performance/stage
Equalizer	Yes
Product color	Black, Grey
Connectivity technology	Wired

Weight and Dimensions

Weight	5500 g
