Plastic Part
Quantity Item Rev Description Reference Designators Notes
1 4.0000 G51-01200-01762 FEET;RUBBER;STANDARD;SELF-
ADHESIVE;COLOR:BLK;DWG.NO:01762
2 1.0000 G52-00000-20109 PLASTIC;P0AEJ;ENCODER KNOB;REV:A
3 1.0000 G52-00000-20110 PLASTIC;P0AEJ;LEFT BUTTON;REV:A
4 1.0000 G52-00000-20112 PLASTIC;P0AEM;POWER BUTTON;REV:A
5 4.0000 G54-00000-20117 PLASTIC;P0AEM;VOLUME PET FILM;REV:A
6 1.0000 G54-00000-20191 PLASTIC;P0AEJ;LCD LENS;REV:A
7 1.0000 G58-00000-20113 PLASTIC;P0AEJ;USB COVER;RUBBER;REV:B
8 2.0000 G58-00000-20114 PLASTIC;P0AEM;VOLUME COVER;REV:A
9 2.0000 G58-00000-20116 PLASTIC;P0AEM;VOLUME KNOB;REV:A
10 2.0000 G58-00000-23466 PLASTIC;P0AEJ;VOLUME PIPE RING
11 1.0000 G58-00000-31827 PLASTIC;P0AEM;HANDLE ASSY;LEFT;REV:A
12 1.0000 G58-00000-31828 PLASTIC;P0AEM;HANDLE ASSY;RIGHT;REV:A
13 1.0000 G58-00000-40254 PLASTIC;P0AEJ;ABS PA757;PANEL;SILVER;GREY;FRONT
PANEL DSP;ABS
14 8.0000 G58-00200-11095 PLASTIC;LEDSPACER
9.5mm;P0502;DST.NO:002;DPT.NO:11095;(P0502-
LEDSPACER_9.5mm-REVB.DWG)
[P0AEJ:01: {8.0}]
15 1.0000 I62-00000-28246 PLASTIC;P0AEJ;RIGHT;BUTTON;A001
16 1.0000 I68-00000-32720 PLASTIC;P0AEO;FRONT_STRIP;A003
17 10.0000 G53-00000-46325 PLASTIC;P0AEN;SILICON RUBBER;SHEET;BLACK;RUBBER
SHEET AMP
[P0AEO:03: {2.0}]
[P0AEO:02: {8.0}]
(EU, UL, JP, UK, SAA,
CCC, AR, BR1)
18 10.0000 G53-00000-46325 PLASTIC;P0AEN;SILICON RUBBER;SHEET;BLACK;RUBBER
SHEET AMP
[P0AEO:03: {2.0}]
[P0AEO:02: {8.0}]
IC8-IC9, T8-T15
19 1.0000 G58-00000-33079 PLASTIC;P0AEN;BLACK;SHIELD PC SHEET [P0AEO:03: {1.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
20 1.0000 G58-00000-33079 PLASTIC;P0AEN;BLACK;SHIELD PC SHEET [P0AEO:03: {1.0}()]
21 6.0000 G53-00000-46348 PLASTIC;P0AEN;SILICON RUBBER;SHEET;BLACK;RUBBER
SHEET DSP
[P0AEO:03: {6.0}] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
22 6.0000 G53-00000-46348 PLASTIC;P0AEN;SILICON RUBBER;SHEET;BLACK;RUBBER
SHEET DSP
[P0AEO:03: {6.0}] D37-D40,T5-T6
To Next Page
