Parts List37 iNUKE NU6000DSP
Ic
Quantity Item Rev Description Reference Designators Notes
1 4.0000 C73-00000-29050 IC;OPAMP;SMD;SOP;8;BA4580RF [P0AEO:02: {4.0}()]
2 1.0000 C73-55035-80508 IC;OPAMP OPAMP;LM358;SOP 8D [P0AEO:02: {1.0}()]
3 2.0000 C73-55617-27408 IC;OPAMP;LM6172IM;SO;PIN:8 [P0AEO:02: {2.0}()]
4 2.0000 C77-00000-19127 IC;VOLT.REGULATOR;DDPAK;3;LM7812 [P0AEO:02: {2.0}()]
5 1.0000 C77-00152-03001 IC;VOLT.REGULATOR;78FC33HT1;3V3 120mA;SOT89 [P0AEJ:01: {1.0}()]
6 1.0000 C77-03128-03001 IC;VOLT.REGULATOR;NCP1117ST33T3;SOT223 [P0AEO:02: {1.0}()]
7 2.0000 C77-05152-03001 IC;VOLT.REGULATOR;78L05;SOT89 [P0AEO:02: {2.0}()]
8 1.0000 C78-55039-32208 IC;COMPARATOR;LM393;SOIC [P0AEO:02: {1.0}()]
9 1.0000 D17-06024-01224 IC;DRAM;IS41LV16105C-50TLI ;1M x 16;TSOP40;SMD;BF [P0AEO:02: {1.0}()]
10 1.0000 D18-96636-41800 IC;DSP;56364;TQFP [P0AEO:02: {1.0}()]
11 1.0000 D19-00037-06553 IC;FLASH;STM32F103RCT6;LQFP64 [P0AEO:02: {1.0}()]
12 2.0000 D22-00070-42608 IC;INVERTER BUFFER;TOSHIBA;TC7WH04FU;SSOP8-P-
0.65
[P0AEO:02: {2.0}()]
13 1.0000 D22-31016-50516 IC;LOGIC;74HC165;SOP [P0AEJ:01: {1.0}()]
14 1.0000 D22-31059-50520 IC;LOGIC;74HC595;SOP [P0AEJ:01: {1.0}()]
15 1.0000 D28-54427-20628 IC;DIGITAL AUDIO;CS4272;AUDIO CODEC;TSSOP28 [P0AEO:02: {1.0}()]
16 4.0000 D28-64295-72216 IC;IRS20957S;SOIC [P0AEO:02: {4.0}()]
17 1.0000 C78-55133-90514 IC;COMPARATOR;(SGS ONLY);LM339;SOP;SMD [P0AEO:03: {1.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
18 2.0000 C74-55031-71403 IC;VOLT.REGULATOR;LM317F;TO220 FULL [P0AEO:03: {2.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
19 1.0000 D30-22002-20108 IC;SWITCH/MULTIPLEX;VIPER22ADIP;DIP-8 [P0AEO:03: {1.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
20 2.0000 D24-16055-57408 IC;MICROCONTROLLER;NE555D;SO8 [P0AEO:03: {1.0}()]
[P0AEO:02: {1.0}()]
(EU, UL, JP, UK, SAA,
CCC, AR, BR1)
21 1.0000 C74-36100-60803 IC;POWER CONVERSION;MCR100-6RLG;TO92;TAPE [P0AEO:03: {1.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
22 1.0000 C74-36100-60803 IC;POWER CONVERSION;MCR100-6RLG;TO92;TAPE [P0AEO:03: {1.0}()]
23 2.0000 C77-00128-03000 IC;VOLT.REGULATOR;ZENERSHUNT.REGULATOR;SOT23;
LM431ACM3/N1
[P0AEO:03: {1.0}()]
[P0AEO:02: {1.0}()]
(EU, UL, JP, UK, SAA,
CCC, AR, BR1)
24 2.0000 C77-00128-03000 IC;VOLT.REGULATOR;ZENERSHUNT.REGULATOR;SOT23;
LM431ACM3/N1
[P0AEO:03: {1.0}()]
[P0AEO:02: {1.0}()]
25 1.0000 C71-20352-50116 IC;DRIVER VOLTAGE-MODE PWM
CONTROLLER;KA3525A;DIP
[P0AEO:03: {1.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
26 1.0000 C71-20352-50116 IC;DRIVER VOLTAGE-MODE PWM
CONTROLLER;KA3525A;DIP
[P0AEO:03: {1.0}()]
