Parts List41 iNUKE NU6000DSP
Plug Socket
Quantity Item Rev Description Reference Designators Notes
1 1.0000 G61-65214-03291 BOX HEADER;POLES:14;2
ROW;STRAIGHT;PITCH:2mm54;SCM-14S
[P0AEO:02: {1.0}()]
2 2.0000 G71-00000-23723 PIN HEADER;DUAL ROW;2*2;P2.54;H=10mm [P0AEJ:01: {2.0}()]
3 1.0000 G71-00000-23725 PIN HEADER;DUAL ROW;2*5;P2.54;H=10mm [P0AEJ:01: {1.0}()]
4 1.0000 G71-23106-04965 PLUG;WAFER;P:2mm;1
ROW;STRAIGHT;POLES:06;TYPE:A2006WV-6P
[P0AEO:02: {1.0}()]
5 1.0000 G71-23108-04747 PLUG;WAFER;POLES:08;1
ROW;STRAIGHT;PITCH:2mm;TYPE:A2006WV-8P
[P0AEO:02: {1.0}()]
6 1.0000 G71-23109-04748 PLUG;WAFER;P:2mm;1
ROW;STRAIGHT;POLES:09;TYPE:A2006WV-9P
[P0AEO:02: {1.0}()]
7 3.0000 G71-23102-04756 PLUG;WAFER;P:2mm;1
ROW;STRAIGHT;POLES:02;TYPE:A2006WV-2P
[P0AEO:03: {3.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
8 3.0000 G71-23102-04756 PLUG;WAFER;P:2mm;1
ROW;STRAIGHT;POLES:02;TYPE:A2006WV-2P
[P0AEO:03: {3.0}()]
9 1.0000 G67-30103-01969 SOCKET;AC;PCB MOUNT;COLOR:BLACK;POLES:03;(SS-
7B-1-T7NUT2)
[P0AEO:03: {1.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
10 1.0000 G67-30103-01969 SOCKET;AC;PCB MOUNT;COLOR:BLACK;POLES:03;(SS-
7B-1-T7NUT2)
[P0AEO:03: {1.0}()]
Power Supply
Quantity Item Rev Description Reference Designators Notes
1 1.0000 J63-00000-28559 TRANSFORMER;P0AEN;EEL1927 CLICK [P0AEO:03: {1.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
2 1.0000 J63-00000-22405 TRANSFORMER;P0AEN;EE55/55/21 [P0AEO:03: {1.0}()] (EU, UL, UK, SAA,
CCC, AR, BR1)
3 1.0000 J63-00000-28559 TRANSFORMER;P0AEN;EEL1927 CLICK [P0AEO:03: {1.0}()]
4 1.0000 J63-00000-40111 TRANSFORMER;P0AAQ;EE55 L:250uH+/-
10%1KHZ,0.25V SG
[P0AEO:03: {1.0}()] (JP)
Quarz
Quantity Item Rev Description Reference Designators Notes
1 1.0000 H65-10400-24576 QUARZ;RESONATOR;24MHz576;HC49S FUNDAMENTAL [P0AEO:02: {1.0}()]
2 1.0000 H65-40471-20000 QUARZ;RESONATOR;12MHz;HC49/4H FUNDAMENTAL [P0AEO:02: {1.0}()]

Behringer iNuke NU6000DSP Specifications

General

Amplifier class	D
Audio output channels	- channels
Peak power per channel	6000 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %
RMS power output per channel (4 Ohm)	3100 W
RMS power output per channel (8 Ohm)	1600 W
USB 2.0 ports quantity	1
Speakers connectivity type	XLR / 1/4\
Purpose	Performance/stage
Equalizer	Yes
Product color	Black, Grey
Connectivity technology	Wired

Weight and Dimensions

Weight	5500 g
