Behringer iNuke NU6000DSP Service Manual

behringer.com
Parts List33 iNUKE NU6000DSP
Diode
Quantity Item Rev Description Reference Designators Notes
1 4.0000 C11-07030-09902 DIODE;BAV99;SOT23 [P0AEO:02: {4.0}()]
2 4.0000 C12-14200-04303 DIODE;ZMM04V3;SMD1206 [P0AEO:02: {4.0}()]
3 1.0000 C14-51775-00800 DIODE;BRIDGE;RBV5008;800V;50A [P0AEO:03: {1.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
4 1.0000 C11-20430-00124 DIODE;SUPERFAST;ER1J;600V;1A;35NS;DO-214AA;SMD [P0AEO:03: {1.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
5 1.0000 C12-14200-09103 DIODE;ZMM09V1;SMD1206 [P0AEO:03: {1.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
6 1.0000 C14-51775-00800 DIODE;BRIDGE;RBV5008;800V;50A [P0AEO:03: {1.0}()]
7 6.0000 C12-14200-15003 DIODE;ZMM15V0;SMD1206 [P0AEO:03: {2.0}()]
[P0AEO:02: {4.0}()]
(EU, UL, JP, UK, SAA,
CCC, AR, BR1)
8 6.0000 C12-14200-15003 DIODE;ZMM15V0;SMD1206 [P0AEO:03: {2.0}()]
[P0AEO:02: {4.0}()]
9 1.0000 C12-14200-05103 DIODE;ZMM05V1;SMD1206 [P0AEO:03: {1.0}()] (EU, UL, UK, SAA,
CCC, AR, BR1)
10 1.0000 C13-20430-03403 DIODE;ES3D;DO-214AB [P0AEO:03: {1.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
11 1.0000 C12-14200-09103 DIODE;ZMM09V1;SMD1206 [P0AEO:03: {1.0}()]
12 4.0000 C13-00000-25853 DIODE;RECTIFIER;SMA;1A;1000V;GS1MW [P0AEO:03: {4.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
13 2.0000 C11-08000-20063 DIODE;1.5KE200A;DO201AD [P0AEO:03: {2.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
14 6.0000 C10-18700-54083 DIODE;SCHOTTKY;SS0540;SOD123;SMD [P0AEO:03: {6.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
15 2.0000 C11-08000-20063 DIODE;1.5KE200A;DO201AD [P0AEO:03: {2.0}()]
16 6.0000 C10-18700-54083 DIODE;SCHOTTKY;SS0540;SOD123;SMD [P0AEO:03: {6.0}()]
17 11.0000 C11-09014-14802 DIODE;LL4148;LL34;TEMIC OR FC [P0AEO:03: {7.0}()]
[P0AEO:02: {4.0}()]
(JP)
18 33.0000 C14-20430-00024 DIODE;SUPERFAST;ES1D;200V;1A;15NS;DO-214AC;SMD [P0AEO:03: {5.0}()]
[P0AEO:02: {28.0}()]
(EU, UL, UK, SAA,
CCC, AR, BR1)
19 4.0000 C13-12550-030A2 DIODE;IXYS;DSEP30-04A;400V;30A;TO-247AD [P0AEO:03: {4.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
20 3.0000 C11-20370-00124 DIODE;GP;GS1G;400V;1A;DO-214AC;SMD [P0AEO:03: {3.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
21 2.0000 C11-08330-44021 DIODE;SUPERFAST;MUR440;400V;4A;60NS;DO-201AD [P0AEO:03: {2.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
22 1.0000 C12-14200-18003 DIODE;ZMM18V0;SMD1206 [P0AEO:03: {1.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
