Behringer iNuke NU6000DSP Service Manual

behringer.com
Parts List34 iNUKE NU6000DSP
Quantity Item Rev Description Reference Designators Notes
23 30.0000 C14-20430-00024 DIODE;SUPERFAST;ES1D;200V;1A;15NS;DO-214AC;SMD [P0AEO:03: {2.0}()]
[P0AEO:02: {28.0}()]
(JP)
24 1.0000 C11-20430-00124 DIODE;SUPERFAST;ER1J;600V;1A;35NS;DO-214AA;SMD [P0AEO:03: {1.0}()]
25 2.0000 C11-08330-44021 DIODE;SUPERFAST;MUR440;400V;4A;60NS;DO-201AD [P0AEO:03: {2.0}()]
26 1.0000 C12-14200-18003 DIODE;ZMM18V0;SMD1206 [P0AEO:03: {1.0}()]
27 3.0000 C11-20370-00124 DIODE;GP;GS1G;400V;1A;DO-214AC;SMD [P0AEO:03: {3.0}()]
28 4.0000 C13-12550-030A2 DIODE;IXYS;DSEP30-04A;400V;30A;TO-247AD [P0AEO:03: {4.0}()]
29 3.0000 C11-19141-10030 DIODE;MBRS1100TR;IR [P0AEO:03: {3.0}()] (JP)
30 1.0000 C13-20430-03403 DIODE;ES3D;DO-214AB [P0AEO:03: {1.0}()]
31 4.0000 C10-00000-12620 DIODE;SCHOTTKY;100 V;SMB;B2100 [P0AEO:03: {4.0}()] (EU, UL, JP, UK, SAA,
CCC, AR, BR1)
32 4.0000 C13-00000-25853 DIODE;RECTIFIER;SMA;1A;1000V;GS1MW [P0AEO:03: {4.0}()]
33 4.0000 C10-00000-12620 DIODE;SCHOTTKY;100 V;SMB;B2100 [P0AEO:03: {4.0}()]
34 12.0000 C11-09014-14802 DIODE;LL4148;LL34;TEMIC OR FC [P0AEO:03: {8.0}()]
[P0AEO:02: {4.0}()]
(EU, UL, UK, SAA,
CCC, AR, BR1)
Display
Quantity Item Rev Description Reference Designators Notes
1 1.0000 C25-00000-20106 DISPLAY;LCD;128*32; NEGATIVE;iNUKE [P0AEJ:01: {1.0}()]

Behringer iNuke NU6000DSP Specifications

General

Amplifier class	D
Audio output channels	- channels
Peak power per channel	6000 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %
RMS power output per channel (4 Ohm)	3100 W
RMS power output per channel (8 Ohm)	1600 W
USB 2.0 ports quantity	1
Speakers connectivity type	XLR / 1/4\
Purpose	Performance/stage
Equalizer	Yes
Product color	Black, Grey
Connectivity technology	Wired

Weight and Dimensions

Weight	5500 g
