Parts List38 iNUKE NU6000DSP
Quantity Item Rev Description Reference Designators Notes
27 2.0000 D24-16055-57408 IC;MICROCONTROLLER;NE555D;SO8 [P0AEO:03: {1.0}()]
[P0AEO:02: {1.0}()]
28 1.0000 D30-22002-20108 IC;SWITCH/MULTIPLEX;VIPER22ADIP;DIP-8 [P0AEO:03: {1.0}()]
29 1.0000 C78-55133-90514 IC;COMPARATOR;(SGS ONLY);LM339;SOP;SMD [P0AEO:03: {1.0}()]
30 2.0000 C74-55031-71403 IC;VOLT.REGULATOR;LM317F;TO220 FULL [P0AEO:03: {2.0}()]
Led
Quantity Item Rev Description Reference Designators Notes
1 8.0000 E10-00000-25912 LED HIB;3mm0 ROUND;RED;Len: RED Diffuse;Iv:500mcd [P0AEJ:01: {8.0}()]
2 6.0000 E10-00000-28393 LED HIB;3mm0
ROUND;AMBER;DIFFUSED;w/RING;605;Iv:900mcd
[P0AEJ:01: {6.0}()]
3 8.0000 E10-51610-05431 LED;HIGH BRIGHT;3mm ROUND;AMBER;NO
RING;WAVELENGTH:610nm
[P0AEJ:01: {8.0}()]
Manual
Quantity Item Rev Description Reference Designators Notes
1 1.0000 A56-00000-56789 SERVICE INFORMATION SHEET;P0000;EN;Contact
Information Sheet:EN;REV:002
2 1.0000 A57-00003-12001 PRODUCT LEAFLET;FOR 2008 FULL LINE CATALOG
3 1.0000 A52-00000-42338 WARRANTY CARD;P0000;EN;REV:001 (AR)
4 1.0000 A54-00000-45724 QUICK START GUIDE;P0AEJ;WW;REV:004 (EU, UL, UK, SAA, AR,
BR1)
5 1.0000 A54-00000-45726 QUICK START GUIDE;P0AEJ;JA;REV:003 (JP)
6 1.0000 A54-00000-45728 QUICK START GUIDE;P0AEJ;ZH;REV:003 (CCC)
7 1.0000 A52-00000-40142 WARRANTY CARD;P0000;JA;DATE:01.07.2011;REVD (JP)

Behringer iNuke NU6000DSP Specifications

General

Amplifier class	D
Audio output channels	- channels
Peak power per channel	6000 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %
RMS power output per channel (4 Ohm)	3100 W
RMS power output per channel (8 Ohm)	1600 W
USB 2.0 ports quantity	1
Speakers connectivity type	XLR / 1/4\
Purpose	Performance/stage
Equalizer	Yes
Product color	Black, Grey
Connectivity technology	Wired

Weight and Dimensions

Weight	5500 g
