Behringer XENYX X1622USB User Manual

XENYX X1622USB/X2222USB/X2442USB • pg 20
www.behringer.com
XENYX X1622USB/X2222USB/X2442USB • pg 21
www.behringer.com
EN
ES
FR
X1622USB/X2222USB/X2442USB
Multi-FX Processor Preset Chart
No. Eect PROGRAM Min. value Max. value Default TAP Min. value Max. value Default TAP LED
REVERB
01
HALL Reverb time 01 (approx.
1.0 sec.)
10 (approx.
8.0 sec.)
03 Brilliance oF on on off/on lighting
02
ROOM Reverb time 01 (approx.
0.5 sec.)
10 (approx.
4.0 sec.)
04 Brilliance oF on oF off/on lighting
03
PLATE Reverb time 01 (approx.
0.5 sec.)
10 (approx.
5.0 sec.)
03 Brilliance oF on on off/on lighting
04
GATED Reverb time 01 (approx.
0.1 sec.)
10 (approx.
1.0 sec.)
02 Brilliance oF on oF off/on lighting
05
REVERSE Reverb time 01 (approx.
0.1 sec.)
10 (approx.
1.0 sec.)
05 Brilliance oF on oF off/on lighting
AMBIENCE / DELAY
06
EARLY REFLECTIONS Room size 01 (small) 10 (extra large) 05 Brilliance oF on oF off/on lighting
07
AMBIENCE Area size 01 (small) 10 (extra large) 05 Brilliance oF on on off/on lighting
08
DELAY No. of
repetitions
01 (min.
feedback)
20 (max.
feedback)
04 Time Interval
(BPM)
07 (72 BPM) 60 (600 BPM) 12 (120 BPM) blinks BPM
Tempo
09
ECHO No. of
repetitions
01 (min.
feedback)
40 (max.
feedback)
20 Time Interval
(BPM)
07 (72 BPM) 60 (600 BPM) 10 (100 BPM) blinks BPM
Tempo
MODULATION
10
CHORUS Intensity
(Depth)
01 (1 %) 99 (99 %) 30 Tempo
(LFO-Speed)
02 (24 BPM) 48 (480 BPM) 06 (60 BPM) blinks mod speed
11
FLANGER Intensity
(Depth)
01 (1 %) 99 (99 %) 40 Tempo
(LFO-Speed)
02 (24 BPM) 48 (480 BPM) 09 (90 BPM) blinks mod speed
12
PHASER Intensity
(Depth)
01 (1 %) 99 (99 %) 60 Tempo
(LFO-Speed)
02 (24 BPM) 48 (480 BPM) 03 (30 BPM) blinks mod speed
DETUNE / PITCH
13
DETUNE Detune-
Spreading
01 (1 cent) 99 (99 cent) 25 2nd voice delay 05 (short,
5 ms)
50 (long, 50
ms)
05 (5 ms) off/on lighting
14
PITCH SHIFT Semitone
Steps
-12 (1 octave
down)
12 (1 octave up) 03 (Minor
3rd)
Detune oF (0 Cent) on (+25 cent) oF (0 Cent) off/on lighting
COMBINATION FX
15
DELAY + REV Ratio -9 (90% DLY,
10% REV)
9 (10% DLY,
90% REV)
0 (50%/
50%)
DLY Time (BPM) 11 (116 BPM) 60 (600 BPM) 12 (120 BPM) blinks BPM
Tempo
16
CHORUS + REV Ratio -9 (90% CH,
10% REV)
9 (10% CH,
90% REV)
0 (50%/
50%)
Reverb time 12 (short,
1.2 s)
24 (long,
2.4 s)
12 (short,
1.2 s)
off/on lighting
Specifications
Mono inputs X1622USB X2222USB X2442USB
Microphone inputs
(XENYX Mic preamp)
4 8 10
Type XLR connector, electronically balanced, discrete input circuit
Mic E.I.N.1 (20 Hz - 20 kHz)
@ 0 Ω source resistance -134 dB 135.7 dB A-weighted
@ 50 Ω source resistance -131 dB 133.3 dB A-weighted
@ 150 Ω source resistance -129 dB 130.5 dB A-weighted
Frequency response (–1 dB) <10 Hz - 150 kHz (-1 dB)
Frequency response (–3 dB) <10 Hz - 200 kHz (-3 dB)
Gain range +10 dB to +60 dB
Max. input level +12 dBu @ +10 dB GAIN
Impedance 2.6 k Ohms balanced
Signal-to-noise ratio 110 dB A-weighted (0 dBu In @ +22 dB GAIN)
Distortion (THD+N) 0.005% / 0.004% A-weighted
Phantom Power Switchable, +48 V
Line input
Type ¼" TRS jack, electronically balanced
Impedance 20 k Ohms balanced, 10 k Ohms unbalanced
Gain range -10 dB to +40 dB
Max. input level 30 dBu
Frequency response (Mic In - Main Out)
<10 Hz - 90 kHz +0 dB / -1 dB
<10 Hz - 160 kHz +0 dB / -3 dB
Stereo inputs
Type 4 dual ¼" TRS jacks, balanced
Impedance 20 k Ohms balanced, 10 k Ohms unbalanced
Gain range -20 dB to +20 dB
Max. input level +22 dBu
2-TRACK/USB Input
Type RCA connector
Impedance 10 k Ohms
Max. input level +22 dBu
Equalizer 3-band Equalizer 3-band semi-parametric
LOW 80 Hz / +- 15 dB
MID Variable 100 Hz - 8 kHz / +- 15 dB
HIGH 12 kHz / +- 15 dB
Equalizer 4-band xed Equalizer 4-band xed
LOW 80 Hz / +- 15 dB
LOW MID 500 Hz / +- 15 dB
HIGH MID 3 kHz / +- 15 dB
HIGH 12 kHz / +- 15 dB
Channel inserts
Type
4 x ¼" TRS jacks,
unbalanced
8 x ¼" TRS jacks,
unbalanced
8 x ¼" TRS jacks,
unbalanced
Max. input level +22 dBu
AUX sends
Type
2 x ¼" mono jack,
unbalanced
3 x ¼" mono jack,
unbalanced
4 x ¼" mono jack,
unbalanced
Impedance 120 Ohms
Max. output level +22 dBu
AUX returns X1622USB X2222USB X2442USB
Type
2 dual ¼" TRS
connectors, balanced
3 dual ¼" TRS
connectors, balanced
4 dual ¼" TRS
connectors, balanced
Impedance 20 k Ohms balanced, 10 k Ohms unbalanced
Max. input level +22 dBu
Main outputs
Type XLR, ¼", electronically balanced
Impedance 240 Ohms balanced, 120 Ohms balanced
Max. output level +28 dBu
Control room output
Type ¼" TS connector, unbalanced
Impedance 120 Ohms
Max. output level +22 dBu
Phones output
Type ¼" TRS jack, unbalanced
Max. output level +19 dBu / 150 Ohms (+25 dBm)
2-TRACK/USB Output
Type RCA connector
Impedance 1 k Ohms
Max. output level +22 dBu
DSP
Converter
24-bit Delta-Sigma
64/128-times oversampling
Sampling Rate 40 kHz
Main mix system data (Noise)
Main mix @ -∞,
channel fader @ -∞
-105 dB / -108 dB A weighted
Main mix @ 0 dB,
channel fader @ -∞
-95 dB / -97 dB A weighted
Main mix @ 0 dB,
channel fader @ 0 dB
-82.5 dB / -85 dB A weighted
Power supply
Mains voltage 100 - 240 V~, 50/60 Hz
Power consumption 50 W
Fuse (100 - 120 V~, 50/60 Hz) T 1,6 A H 250 V
Fuse (220 - 230 V~, 50/60 Hz) T 1,6 A H 250 V
Mains connector Standard IEC receptacle
USB
Audio Stereo In/Out
Connector Type B
Converter 16-bit
Sample Rate 48 kHz
Physical/weight
Dimensions (H x W x D)
90mmx320mmx
340mm (3.54" x 12.60"
x 13.39")
90mmx430mmx
355mm (3.54" x 16.93"
x 14")
135mmx440mmx
420mm (5.31" x 17.32"
x 16.54")
Weight 7.60 lbs / 3.45kg 10.5 lbs / 4.78kg 13 lbs / 5.92kg

Behringer XENYX X1622USB Specifications

General

Equalizer bands quantity	3
Frequency range	10 - 200000 Hz
Channels quantity	16 channels
Line Signal-to-Noise Ratio (SNR)	30 dB
Video capability	No
Microphone input impedance	2600 Ω

Weight and Dimensions

Depth	320 mm
Width	340 mm
Height	90 mm
Weight	4180 g
