Beijer Electronics X2 Series User Manual

X2 series with embedded CODESYS control – Recommendations and limitations
SUEN00392E 2022-03
57 (61)
Normal.dotm
, 2020-09-09
Import of variables
At this stage, it’s time to import the xml-file that was exported from CODESYS.
• Go to the tab Tags
• In the window, choose the Import tags to option and select the controller name
• Browse to the location where the project is saved
• Select the xml file with the same name as the project
• Click Import
• A import dialog will appear, select All items and press OK

Beijer Electronics X2 Series Specifications

General

Brand	Beijer Electronics
Model	X2 Series
Category	Controller
Language	English
