GN-9289 User Manual
Page 55 of (70)
G-series GN-9289 Modbus TCP_UDP Rev. 1.01.docx
9.4. Assembly Object
Class Code: 04
HEX
9.4.1 Common Services
Service Code
Implemented for
Service Name
Class
Instance
0x0E
Yes
Yes
Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
9.4.2 Class Attributes
Instance
ID
Attribute
ID
Access
Rule
Name Data Type Value
0
1
Get
Revision
UINT
0002
HEX
9.4.3 Class Attributes
Insta
nce
ID
Attrib
ute ID
Acce
ss
Rule
Name
Data
Type
Value
1 3 Get
Input (Produced)
Process Image
Data
Array
BYTE
n
Input process image data
2 3
Set/G
et
Output (Consumed)
Process Image
Data
Array
BYTE
n
Output process image data
9.5 Connection Manager Object
Class Code: 06
HEX
9.5.1 Class Attributes, Instance Attribute
None
