6.4.2 IP-Address Setup using DIP switch (Manual function)
If the adapter DIP Pole#10 is ON, lowest IP address is set by DIP Pole#1~#8 manually.
These are examples of adapter IP-Address setup by manual function.
Ex) XXX. XXX. XXX. 1
Ex) XXX. XXX. XXX. 2
Ex) XXX. XXX. XXX. 8
Ex) XXX. XXX. XXX. 253
