GN-9289 User Manual
Page 57 of (70)
G-series GN-9289 Modbus TCP_UDP Rev. 1.01.docx
9.7 TCP/IP Object
Class Code: F5 HEX
9.7.1. Common Services
Service Code
Implemented for
Service Name
Class
Instance
0x01 Yes Yes Get_Attribute_All
0x0E
Yes
Yes
Get_Attribute_Single
0x02
No
Yes
Set_Attribute_All
0x10
No
Yes
Set_Attribute_Single
9.7.2. Class Attributes
Instance
ID
Attribute
ID
Access
Rule
Name Data Type Value
0
1
Get
Revision
UINT
0001
HEX
2
Get
Max Instance
UINT
0001
HEX
3
Get
Num Instances
UINT
9.7.3. Instance Attributes
Instance
ID
Attribute
ID
Access
Rule
Name Data Type Value
1
1
Get
Status
DWORD
See section 4.7.3.1.
2 Get
Configuration
Capability
DWORD 00000006
H EX
3
Get/Set
Configuration Control
DWORD
See section 4.7.3.2.
4 Get
Physical Link Path
Size of Path
Path
STRUCT of:
UINT
Padded-
PATH
0002
HEX
00 00 20 F6 24 01
5 Get/Set
Interface
Configuration
STRUCT of:
UDINT
UDINT
UDINT
UDINT
UDINT
STRING
IP address
Network Mask
Gateway Address
Name Server
Name Server 2
Domain Name
