GN-9289 User Manual
Page 59 of (70)
G-series GN-9289 Modbus TCP_UDP Rev. 1.01.docx
9.8. Ethernet Link Object
Class Code: F6 HEX
9.8.1. Common Services
Service
Code
Implemented for
Service Name
Class
Instance
0x01
Yes
Yes
Get_Attribute_All
0x0E
Yes
Yes
Get_Attribute_Single
9.8.2. Class Attributes
Instance
ID
Attribute
ID
Access
Rule
Name Data Type Value
0
1
Get
Revision
UINT
0002
HEX
2
Get
Max Instance
UINT
0001
HEX
3
Get
Num Instances
UINT
0001
HEX
