Beissbarth BAC 5100yf - Filter Change

30
Maintenance
Caution: To prevent equipment damage,
use only authentic Beissbarth No.
SP01100355 lters in this machine. All
performance tests and claims are based
on using this specic lter.
WARNING: To prevent personal
injury while working with
refrigerant, read and follow the
instructions and warnings in
this manual, and wear protective
equipment such as goggles and
gloves.
Filter Change
Thelterisdesignedtotrapacidandparticulates,
andtoremovemoisturefromrefrigerant.Tomeet
themandateforadequatemoistureandcontaminant
removal,theltermustbereplacedafter150kg(331
lbs.)ofrefrigeranthasbeenltered.
Themachinegivesawarningwhen125kg(276lbs.)
oftheltercapacityhasbeenused;themachinelocks
downwhenthe150kg(331lb.)ltercapacityhasbeen
reachedandwillnolongerfunction.
Check Remaining Filter Capacity
1.SelectFILTER CHANGEfromtheSetupMenuor
whenthemachineprompts.Themachinedisplays
FILTERLIFETIME:X.XXKG
REPLACEFILTER?
 Themachinedisplaystheamountofltercapacity
remaininguntilthemachinelocksdown.
2.Whenprompted,selectOKtochangethelter;
selectESC toresumeusingthemachine.
WARNING: The components in the machine are
under high pressure. To prevent personal injury,
change the lter only when the machine prompts.
Replace the Filters and Sample Hose Assembly
1.IfOK wasselectedtochangethelter,themachine
clearsthelter,thenpromptsforthenewltercode
tobeentered.
WAITINGFORFILTERTOBECLEARED
FILTERSERIAL#
 Usethekeypadtoentertheserialnumberthat
appearsonthenewlterandselectOK.IfSERIAL
NUMBERWRONGisdisplayed,theserialnumber
hasbeenincorrectlyentered,orthelterhasalready
beenusedinthismachine.
2.Themachinedisplays
TURNUNITOFF
REMOVESHROUDANDREPLACEFILTER,
IDENTIFIERFILTER,AND
IDENTIFIERSAMPLEHOSEASSEMBLY
 Shutoffthemachine.Removetheoilbottle.Remove
thefourscrewsholdingtheshroud.SeeFigure15.
Figure 15
Remove the four screws
holding the shroud.
