Beissbarth BAC 5100yf - Page 9

7
BAC 5100yf Rev. A
Item
No.
Description
1
OilDrainBottle
2 Printer
3
Low-side(blue)andHigh-side(red)ManifoldGauges
4 GraphicDisplayandKeypad
5 PowerON/OFFSwitch
6
Audio,ethernet,USB,mini-USB,andSDcardConnections;2224Vms
doubleinsulationinrespecttomainlines
7 VacuumPumpOilSightGlass
8 VacuumPumpOilOilDrainFitting
9 WheelLock
10 VisualAlert
11 VacuumPumpOilFillCapandPort
12 OilInjectBottle1(whitecover)
13 OilInjectBottle2(greencoloroncover)
14 ContaminantRecoveryPort
15 UVDyeInjectBottle3(yellowcoloroncover)
16 Lockout/Tagout
17 ServiceHoseStoragePorts
Introduction
Features of the BAC 5100yf
continued
