BelAir20E User Guide Layer 2 Network Configuration
April 2, 2012 Confidential Page 190 of 255
Document Number BDTM02201-A01 Standard
13 wifi-2-1-5 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
14 wifi-2-1-6 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
15 wifi-2-1-7 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
16 wifi-2-1-8 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
17 wifi-3-1-1 60:00:00:23:34:b0:3e:80 200000 90:00:00:0d:67:00:69:5e 80:11
18 wifi-3-1-2 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
19 wifi-3-1-3 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
20 wifi-3-1-4 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
21 wifi-3-1-5 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
22 wifi-3-1-6 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
23 wifi-3-1-7 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
24 wifi-3-1-8 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
25 wifi-4-1-1 60:00:00:23:34:b0:3e:80 200000 90:00:00:0d:67:00:69:5e 80:19
26 wifi-4-1-2 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
27 wifi-4-1-3 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
28 wifi-4-1-4 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
29 wifi-4-1-5 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
30 wifi-4-1-6 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
31 wifi-4-1-7 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
32 wifi-4-1-8 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
33 eth-5-1 60:00:00:23:34:b0:3e:80 0 60:00:00:23:34:b0:3e:80 80:0f
Example 3
/protocol/rstp# show topology port wifi-2-1-1
RSTP Port Topology Information
-------------------------------
Port Name Designated-root Designated Designated-bridge Designated
Interface-link Cost Port
---- -------------- ----------------------- ---------- ----------------------- ----------
9 wifi-2-1-1 00:00:00:00:00:00:00:00 0 00:00:00:00:00:00:00:00 00:00
Example 4
/protocol/rstp# show topology port active
RSTP Port Topology Information
-------------------------------
Port Name Designated-root Designated Designated-bridge Designated
Interface-link Cost Port
---- -------------- ----------------------- ---------- ----------------------- ----------
1 wifi-1-1-1 60:00:00:23:34:b0:3e:80 200000 90:00:00:0d:67:00:69:5e 80:01
17 wifi-3-1-1 60:00:00:23:34:b0:3e:80 200000 90:00:00:0d:67:00:69:5e 80:11
25 wifi-4-1-1 60:00:00:23:34:b0:3e:80 200000 90:00:00:0d:67:00:69:5e 80:19
33 eth-5-1 60:00:00:23:34:b0:3e:80 0 60:00:00:23:34:b0:3e:80 80:0f
