BelAir20E User Guide Wi-Fi Radio Configuration Overview
April 2, 2012 Confidential Page 71 of 255
Document Number BDTM02201-A01 Standard
Wi-Fi Radio Configuration Overview
Available Wi-Fi
Radios
Table 7 on page 71 lists the available BelAir Wi-Fi radios.
Configuration
Process
Use the following process to configure a Wi-Fi radio:
1 Configure basic radio parameters. See “Configuring Wi-Fi Radio
Parameters” on page 72.
2 Configure AP parameters, if required. See “Configuring Wi-Fi Access Point
Parameters” on page 80 and “Wi-Fi AP Security” on page 100.
3 Configure backhaul parameters. See “Wi-Fi Backhaul Link Configuration” on
page 115.
4 Configure mobile backhaul mesh parameters. See “Mobile Backhaul Mesh”
on page 123
Table 7: BelAir Wi-Fi Radio Summary
Radio
Module
Operating
Frequency
Platform
Can
Operate
as Access
Point?
Supported
Backhaul
To p o l o g i e s
HTMEv1 2.4/5.8 GHz BelAir20E Yes mp-to-mp
p-to-mp
p-to-p
