WAVE ACROSS
1MANUL850 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 13
Installation
Utilities
Electrical
CAUTION
It is recommended that a licensed electrician is contracted to perform all electrical
installations.
1) Supply 3-phase power to the motor on top of the frame assembly.
Overhead View
Gearbox
Motor
Main electrical
feed
