Belanger Wave Across - Stud;Retainer Assembly; Stud Retainer with Castle Nut Assembly; Rack Bushing Assembly

WAVE ACROSS
24 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL850
Maintenance
Exploded Parts View
Stud/Retainer Assembly
Stud Retainer with Castle Nut Assembly
Rack Bushing Assembly
1WASHR-LC789
1WASHR-FL830
1FSTNR-HH873
3723
3223
1WASHR-FL830
This assembly is to always be used to secure
the Drive Arm to the Pitman Arm
When replacing the Stud/Retainer Assembly
that mounts to the Pitman Arm, we
recommend you also replace the Pitman Arm
also. They typically wear simultaneously.
Hel
p
ful Hint.
3642
1NUT-CN075
1RETNR635
7506
7508
3223
3723
3223
3723
1RETNR635
1RETNR132
3642
1WASHR-FL830
1NUT-JM500
1WASHR-LC789
1WASHR-FL830
1NUT-JM500
1WASHR-LC789
