Maintenance
Special Attention Items
Mitter Collar Placement
On the Wave Across™, there are six inside collars, which are installed at the factory. They are set as shown below.
Placement typical on all four bearings
Collars are to be butted up
against the side-plates
Collars are to be butted up
against the side-plates
