Belden HIRSCHMANN EAGLE40-03 - Page 45

Installation EAGLE40 Release
02
08/2020
45
-LH+/LC.. LH 1550 nm 9/125 µm 13 dB ... 32 dB 38.52 mi ... 72.07 mi
(62 km ... 116 km)
0.25 dB/km
(typically)
19 ps/(nm×km)
-LH+/LC.. LH 1550 nm 9/125 µm 13 dB ... 32 dB 38.52 mi ... 85.75 mi
(62 km ... 138 km)
0.21 dB/km
(typically)
19 ps/(nm×km)
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
b. including 3 dB system reserve when compliance with the fiber data is observed
c. Using the bandwidth length product is inappropriate for expansion calculations.
d. With F/O adapter compliant with IEEE 802.3-2002 clause 38 (single-mode fiber offset-launch mode conditioning patch cord)
e. With F/O adapter compliant with IEEE 802.3-2002 clause 38 (single-mode fiber offset-launch mode conditioning patch cord)
f. Including 2.5 dB system reserve when compliance with the fiber data is observed
Product code
SFP-GIG-B...
Mode
a
Mode
a. MM = Multimode, SM = Singlemode, LH = Singlemode Longhaul
Wave length
TX
Wave length
RX
Fiber System
attenuation
Example for F/O
line length
b
b. including 3 dB system reserve when compliance with the fiber data is observed
Fiber
attenuation
Dispersion
SFP-GIG-BA LX/
LC EEC
SM 1310 nm 1550 nm 9/125 µm 0 dB ... 15 dB 0 mi ... 12.42 mi
(0 km ... 20 km)
0.4 dB/km 3.5 ps/(nm×km)
SFP-GIG-BB LX/
LC EEC
SM 1550 nm 1310 nm 9/125 µm 0 dB ... 15 dB 0 mi ... 12.43 mi
(0 km ... 20 km)
0.25 dB/km 19 ps/(nm×km)
SFP-GIG-BA
LX+/LC EEC
SM 1310 nm 1550 nm 9/125 µm 3 dB ... 20 dB 7.45 mi ... 24.86 mi
(12 km ... 40 km)
0.4 dB/km 3.5 ps/(nm×km)
SFP-GIG-BB
LX+/LC EEC
SM 1550 nm 1310 nm 9/125 µm 3 dB ... 20 dB 7.45 mi ... 24.86 mi
(12 km ... 40 km)
0.25 dB/km 19 ps/(nm×km)
SFP-GIG-BA LH/
LC EEC
SM 1490 nm 1550 nm 9/125 µm 4 dB ... 24 dB 11.80 mi ... 49.71 mi
(19 km ... 80 km)
0.25 dB/km 19 ps/(nm×km)
SFP-GIG-BB LH/
LC EEC
SM 1550 nm 1490 nm 9/125 µm 4 dB ... 24 dB 11.80 mi ... 49.71 mi
(19 km ... 80 km)
0.25 dB/km 19 ps/(nm×km)
Table 12: F/O port (bidirectional Gigabit Ethernet SFP Transceiver)
Product code
M-SFP-...
Mode
a
Wave length Fiber System
attenuation
Example for F/O line
length
b
Fiber attenuation BLP
c
/
dispersion
Table 11: Fiber port 1000BASE-FX (SFP fiber optic Gigabit Ethernet Transceiver)
