44
Installation EAGLE40
Release
02
08/2020
 Network range
Note: The line lengths specified for the transceivers apply for the respective fiber data (fiber attenuation and BLP/
dispersion).
Product code
M-SFP-...
Mode
a
Wave length Fiber System
attenuation
Example for F/O line
length
b
Fiber attenuation BLP
c
/
dispersion
-SX/LC... MM 850 nm 50/125 µm 0 dB ... 7.5 dB 0 mi ... 0.34 mi
(0 km ... 0.55 km)
3.0 dB/km 400 MHz×km
-SX/LC... MM 850 nm 62.5/125 µm 0 dB ... 7.5 dB 0 mi ... 0.17 mi
(0 km ... 0.275 km)
3.2 dB/km 200 MHz×km
-MX/LC... MM 1310 nm 50/125 µm 0 dB ... 12 dB 0 mi ... 0.93 mi
(0 km ... 1.5 km)
1.0 dB/km 800 MHz×km
-MX/LC... MM 1310 nm 62.5/125 µm 0 dB ... 12 dB 0 mi ... 0.31 mi
(0 km ... 0.5 km)
1.0 dB/km 500 MHz×km
-LX/LC... MM 1310 nm
d
50/125 µm 0 dB ... 10.5 dB 0 mi ... 0.34 mi
(0 km ... 0.55 km)
1.0 dB/km 800 MHz×km
-LX/LC... MM 1310 nm
e
62.5/125 µm 0 dB ... 10.5 dB 0 mi ... 0.34 mi
(0 km-0.55 km)
1.0 dB/km 500 MHz×km
-LX/LC... SM 1310 nm 9/125 µm 0 dB ... 10.5 dB 0 mi ... 12.42 mi
(0 km ... 20 km
f
)
0.4 dB/km 3.5 ps/(nm×km)
-LX+/LC... SM 1310 nm 9/125 µm 5 dB ... 20 dB 8.7 mi ... 26.10 mi
(14 km ... 42 km)
0.4 dB/km 3.5 ps/(nm×km)
-LH/LC... LH 1550 nm 9/125 µm 5 dB ... 22 dB 14.29 mi ... 49.71 mi
(23 km ... 80 km)
0.25 dB/km 19 ps/(nm×km)
-LH+/LC LH 1550 nm 9/125 µm 15 dB ... 30 dB 44.12 mi ... 67.11 mi
(71 km ... 108 km)
0.25 dB/km 19 ps/(nm×km)
-LH+/LC LH 1550 nm 9/125 µm 15 dB ... 30 dB 44.12 mi ... 79.54 mi
(71 km ... 128 km)
0.21 dB/km
(typically)
19 ps/(nm×km)
Table 11: Fiber port 1000BASE-FX (SFP fiber optic Gigabit Ethernet Transceiver)
