Belden HIRSCHMANN iFLEX2 + iSCOUT expert compact - E61 - Flow Chart

Service Manual iFLEX2 with iSCOUT expert compact
22 50 650 69 0101E_REV D (GROVE RT-TM).DOC / Rev. D / 2015-11-20 / JPD
12.1.1 E61 - Flow Chart
E61
Connect the two cables on the
Transducer block together
E61
Yes
Disconnect cables and connect cable
from c/u to transducer block
E61
Yes
No
Ohm cable from c/u to the
transducer block. If cable checks
good replace c/u
Connect the cable reel can bus cable to
the transducer block. Remove can bus
connector at cable reel
E61
Yes
Replace can bus cable between
Cable reel and transducer block
No
Ohm out connector in cable reel.
If connector checks good, replace can bus
converter board.
E62
Replace Transducer Block
E64
E64
