16 ERROR CODES
The following Error Code Table gives a brief description of Error Codes elimination. Refer to the
noted sections for detailed Troubleshooting information.
LMI System Error Code Table (LSQG V 1.xx):
Error code
Error
Cause
Elimination
E01
Fallen below radius range or
angle range exceeded
 Fallen below the minimum
radius or gone past the
maximum angle specified in
the respective load chart due
to luffing up the boom too far
 Luff down the boom to a radius
or angle specified in the load
chart.
E02
Radius range exceeded or
fallen below angle range
 Gone past the maximum
radius or fallen below the
minimum angle specified in
the respective load chart due
to luffing down the boom too
far
 Luff up the boom to a radius or
angle specified in the load
chart.
E03
Non-permitted slewing zone (no
load area)
 The slewing zone with load is
not permitted
 Slew to permitted area
E04
Operating mode not
acknowledged or non permitted
slewing zone
 A non existing operating
mode has been selected
 Set the correct operating mode
for the operating state in
question
 The boom is in a non-
permitted slewing zone
 Slew the boom to a permitted
area.
E05
Prohibited length range
 Boom has been extended
either too far or not far
enough, e.g. if it is prohibited
to go beyond a certain
maximum boom length or with
load curves for jibs where the
main boom has to be
extended to a certain length
 Extend/retract boom to the
correct length
 Length sensor adjustment
has changed, e.g. the cable
slid off the length sensor reel.
 Retract boom. Check the
prestress of the cable reel
(cable must be taut). Open the
length sensor and carefully turn
the length sensor pot
counterclockwise until the
detent by means of a screw
driver
 Clutch between length sensor
pot and drive is defective
 Replace the complete clutch
including drive wheel and
adjust length sensor pot as
described above
E06
Radius range exceeded or
fallen below angle range with
luffing jib operation
 Maximum radius as specified
in the load chart exceeded or
fallen below minimum angle
due to luffing down the luffing
jib too far
 Luff the jib to a radius or angle
specified in the load chart.
E11
Fallen below lower limit value
for measuring channel "length
main boom"
 Length potentiometer is
defective
 PDB variable for analog value
not supported
 Replace length potentiometer
 Setup of correct PDB variable
for analog value in DGA6.i.3
 Electronic component in the
measuring channel is
defective
 Replace sensor unit
E12
Fallen below the lower limit
value in the measuring channel
"pressure piston side"
 Pressure transducer is
defective.
 PDB variable for analog value
not supported
 Replace pressure transducer
 Setup of correct PDB variable
for analog value in DGA6.i.3
 Electronic component in the
measuring channel is
defective.
 Replace sensor unit
