4. MAIN PARAMETERS
Main parameters are specified in the Table 1.
Table 1
№ Name
Parameters
BELMASH
SDM-2000
BELMASH
SDM-2200
BELMASH
SDM-2500
1 Max. planing width per pass, mm 230 250 270
2 Range of planing depth per pass, mm 0÷3 0÷3 0÷3
3
Max. height of the work piece pressed by a holding
down device, up to, mm
65 65 65
4
Max. uncut dimensions, length×width×height
(depth), mm
2000×230×85 2000×250×100 2000×270×117
5 Range of cutting depth, mm 0÷85 0÷100 0÷117
6 Range of cutting depth per pass, mm 250 280 315
7 Diameter of disc cutter 125 125 125
8
Diameter of mounting bore of disc cutter/ saw
blade, mm
32 32 32
8 Diameter of end cutter, mm 612 612 612
9
Range of longitudinal cutting angles and planing
with the use of a ruler, degrees
0÷45 0÷45 0÷45
10
Range of cross cutting angles with the use of a
device, degrees
–45÷45 –45÷45 –45÷45
11 Cutting table dimensions, mm 732×456 802×492 872×532
12 Dimensions of tables during planing, mm 760×247 830×267 900×287
13 Milling table dimensions, mm 470×190 470×190 470×190
14
Rated idle RPM of a knife’s block and end cutter,
min
-1
7700 7700 7700
15 Rated idle RPM of a saw blade and disc cutter, min
-1
2850 2850 2850
16 Rated consumed power, W 2000 2200 2500
17 Rated frequency, Hz 230 230 230
18 Rated frequency, Hz 50 50 50
19 Overall dimensions, L×B×H, mm 806×793×445 876×829×460 949×849×512
20
Setting dimension, L
1
×B
1
(min. the size of the site
for the installation of the machine), mm
430×206 430×226 441×246
21 Weight of machine including devices (net/gross), kg 52,4/55,3 56,1/59,2 61,3/64,9
Limit deviations of linear and angular dimensions do not exceed ±5%
Limit deviation of the rotating frequency does not exceed ±5%
Limit deviation of the power consumption +15%
