Description
This setting defines communication parameters for printer serial port.
Syntax
SET COM1 baud, parity, data, stop
Parameter Description
baud Baud rate, available baud rates are as listed :
24: 2400 bps
48: 4800 bps
96: 9600 bps
19: 19200 bps
38: 38400 bps
57: 57600 bps
115: 115200 bps
parity Parity check
N: No parity check
E: Even parity check
O: Odd parity check
Data Data bit
8: 8 bits data
7: 7 bits data
stop Stop bit
1: 1 stop bit
2: 2 stop bits
Example
The parallel port is used to setup the printer serial port in this example via MS-DOS mode.
C:\>COPY CON LPT1<ENTER>
SET COM1 19,N,8,1<ENTER>
<CTRL><Z><ENTER>
C:\>
Note: <ENTER> stands for PC keyboard “ ENTER” key. <CTRL><Z> means to hold PC
keyboard “CTRL” key then press the PC keyboard <Z> key.
